AUTONICS PROXIMITY SENSOR, PR18-5DN

AUTONICS PROXIMITY SENSOR, PR18-5DN Specification

Features
LED Indicator, Reverse polarity protection, Surge protection

Application
Presence and position detection of metal objects

Wireless
No, Wired

Mounting Type
Flush mounting (shielded)

Sensor Type
Inductive Proximity Sensor

Measurement Range
Sensing distance 5 mm 10%

Sensitivity
Adjustable by sensing distance

Interface
Open collector

Cable Length
2 meters

Response Time
2 ms

Operating Temperature
-25C to +70C

Power Consumption
Max. 15 mA

IP Rating
IP67

Signal Type
Discrete (ON/OFF)

Product Type
Proximity Sensor

Material
Nickel-plated brass (housing)

Input
DC 3-wire

Output
NPN Normally Open (NO)

Function
Detection of metallic objects without contact

Usage
Industrial Automation, Factory Equipment

Accuracy
High accuracy, repeatability 0.03 mm

Resolution
Detects movement as fine as set sensing distance

Voltage
12-24 VDC

Weight
Approx. 70 g (including cable)

Body Size (Diameter)
M18

Operation Indicator
Red LED

Housing Color
Metallic silver

Cable Specification
3-wire, 4 mm, PVC

Approvals/Certifications
CE, cULus

Hysteresis
10% of sensing distance

Switching Frequency
500 Hz

Control Output Current
Max. 200 mA

Protection Circuit
Reverse polarity, surge protection, output short-circuit protection

About AUTONICS PROXIMITY SENSOR, PR18-5DN

Buy the preeminent AUTONICS PR18-5DN Proximity Sensor and experience sensational performance for industrial automation and factory equipment. This immaculate value sensor features a robust M18 metallic silver housing, adjustable sensitivity, and high precision-delivering repeatability of 0.03 mm and reliable detection of metallic objects. With an IP67 rating, DC 3-wire input, and durable nickel-plated brass build, it is made to withstand harsh conditions. The PR18-5DN offers advanced protection circuits, LED oversight, and a 5 mm sensing range-making it a featured choice for position and presence detection applications.

Advanced Features and Versatile Application Surfaces

The AUTONICS PR18-5DN proximity sensor is built to offer extra features such as a vivid operation indicator, robust surge and reverse polarity protection, and adjustable sensitivity by sensing distance. Its immaculate nickel-plated brass body allows easy flush mounting on various metallic surfaces, ensuring accurate and reliable detection in industrial automation and factory machinery. Ideal for environments demanding high accuracy, it excels in detecting the presence and precise position of metal objects in diverse production setups.

Certified Excellence, Reliable Supply, and Flexible Payment Options

The PR18-5DN sensor comes with CE and cULus certifications, guaranteeing compliance with international standards and performance requirements. Our preeminent supply ability supports fast delivery to exporters, traders, and wholesalers globally, including the China export market. Competitive quotations are available based on your specific needs. We offer flexible payment terms ensuring seamless transactions and prompt shipments to meet demanding industrial schedules and diverse application requirements worldwide.

FAQ's of AUTONICS PROXIMITY SENSOR, PR18-5DN:

Q: How does the AUTONICS PR18-5DN proximity sensor operate?

A: The AUTONICS PR18-5DN works by using inductive technology to detect metallic objects without physical contact. When a metal object enters its sensing range, the sensor activates its output (NPN NO), indicating presence or position.

Q: What extra features enhance the reliability of the PR18-5DN sensor?

A: The PR18-5DN offers sensational features such as reverse polarity and surge protection, output short-circuit protection, an LED operation indicator, and adjustable sensitivity, making it both robust and versatile for demanding industrial environments.

Q: Where can the AUTONICS PR18-5DN be applied?

A: This sensor is ideal for industrial automation, factory equipment, and anywhere accurate non-contact detection of metal objects is required-such as assembly lines, machine tools, and robotic systems.

Q: What certifications does the PR18-5DN hold?

A: The sensor is certified with CE and cULus approvals, ensuring it meets global safety, quality, and performance standards expected in professional and export markets.

Q: When can I expect delivery and how do I request a quotation?

A: We ensure reliable supply and fast delivery to domestic and international markets. Contact our sales team for a quotation tailored to your requirements; we offer competitive terms and prompt responses.

Q: How does the PR18-5DN benefit factory automation processes?

A: Its high accuracy, repeatability, IP67 protection, and fast response time streamline presence and position detection, helping factories achieve greater productivity and operational safety with minimal maintenance.
