AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-15DP

AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-15DP Specification

Sensitivity
Detects ferrous metals within sensing distance

Wireless
No

Measurement Range
15mm (Sensing Distance)

Response Time
Below 2ms

Operating Temperature
-25C to +70C

Signal Type
DC 3-wire, PNP (NO)

Application
Assembly lines, processing equipment, conveyors, machine tools

Mounting Type
Flush/Non-flush mounting

IP Rating
IP67

Features
Short-circuit protection, reverse polarity protection, LED operation indicator

Power Consumption
Max. 20mA

Cable Length
2 meters

Sensor Type
Inductive Proximity Sensor

Interface
Cable Output

Product Type
Proximity Sensor

Material
ABS Plastic (Housing), Nickel-Plated Brass (Sensing Face)

Input
12-24V DC

Output
PNP Normally Open (NO)

Function
Non-contact object detection

Usage
Industrial automation, position detection, object detection

Accuracy
High accuracy, designed for precise sensing

Resolution
Fine detection capability for small displacement

Voltage
12-24V DC

Weight
Approx. 180g

Control Output Capacity
200mA max

Model Number
PSN30-15DP

Detection Target
Ferrous metal (best), reduced distance for non-ferrous

Sensing Method
Inductive, Non-contact

Frequency
450Hz

Housing Size
30mm diameter (Cylindrical)

Indicator
Red LED (Detection Status)

About AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-15DP

Get the eminent AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-15DP today, now available at clearance prices! Pick yours for formidable accuracy in industrial automation and non-contact object detection. This ineffable sensor features a robust 30mm cylindrical body, high-resolution inductive sensing, and flush/non-flush mounting, ensuring versatile integration on assembly lines, conveyors, or machinery. With up to 15mm ferrous metal detection, red LED status indicator, IP67 protection, and PNP-NO output, it meets rigorous demands effortlessly. Boasting short-circuit and reverse polarity protection, the PSN30-15DP delivers long-lasting performance for your critical applications. Act now-secure unparalleled sensing precision!

Advantages & Application Areas of AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-15DP

The AUTONICS PROXIMITY SENSOR PSN30-15DP offers formidable precision and reliability for object and position detection tasks. Its fine detection capability is ideal for demanding applications such as industrial assembly lines, automated conveyors, and machine tools. Frequently used as a critical component in control and automation systems, it ensures precise detection of ferrous metals. Its rugged and IP67-protected design makes it suitable for harsh environments, optimizing operations in industrial facilities and automated process equipment.

Packing, Shipping & Delivery for AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-15DP

Our packing & dispatch procedure guarantees your sensor is well protected, using robust packaging for domestic and international markets. Enjoy express shipping from the main FOB port in China, ensuring swift and safe delivery right to your location. Typically, delivery time ranges from 5-10 business days, depending on the destination. Each package includes the sensor, cable, and installation manual, ensuring you are ready to integrate your new AUTONICS device immediately upon arrival.

FAQ's of AUTONICS PROXIMITY SENSOR 12-24VDC, PSN30-15DP:

Q: How does the AUTONICS PROXIMITY SENSOR PSN30-15DP detect objects?

A: The PSN30-15DP uses an inductive sensing method, detecting the presence of ferrous objects within a 15mm range. Non-ferrous metals can also be detected, though at reduced distances.

Q: What are the main benefits of using the PSN30-15DP in industrial environments?

A: This sensor delivers high accuracy, rapid response time below 2ms, IP67 protection against dust and moisture, and robust reliability, making it suitable for demanding automation applications.

Q: When is the red LED indicator on the sensor activated?

A: The red LED indicator lights up whenever the sensor detects a target object within its specified sensing distance, providing a clear and immediate detection status.

Q: Where can the AUTONICS PSN30-15DP be installed?

A: It supports both flush and non-flush mounting, allowing flexible installation on assembly lines, processing machinery, conveyors, and other automated industrial equipment.

Q: What is the typical process for connecting the PSN30-15DP sensor?

A: Connection is straightforward with the 2-meter cable output and 3-wire DC PNP (NO) configuration. Simply follow the included manual for wiring into your control system.
