AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-8DN, E-X10B1TL18 2M

AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-8DN, E-X10B1TL18 2M Specification

Cable Length
2 Meters Meter (m)

Features
Short-circuit and Overload Protection, LED operation indicator

Power Consumption
Max. 20mA Ampere

Application
Robotics, Conveyors, Packaging Machines, Safety Interlocks

Wireless
No

Operating Temperature
-25C to +70C Celsius (oC)

Sensor Type
Inductive Proximity

Interface
3-wire DC

Mounting Type
Flush Mountable (Embeddable)

Sensitivity
Adjustable via sensor distance

Measurement Range
8mm Sensing Distance

IP Rating
IP67

Signal Type
Digital (ON/OFF)

Product Type
Proximity Sensor

Material
Metal Housing

Input
12-24V DC

Output
NPN Normally Open (NO)

Function
Detects metallic objects without physical contact

Usage
Industrial Automation, Object Detection

Resolution
Precise sensing up to specified range

Voltage
12-24V DC Volt (v)

Weight
Approx. 120g Grams (g)

Connection Type
Pre-wired Cable

Operating Frequency
800Hz

Light Indication
LED (Operation indicator)

Sensing Object
Ferrous Metals (Distance may reduce for non-ferrous metals)

Surface Treatment
Nickel plated

Model Number
PSN17-8DN E-X10B1TL18-2M

Diameter
17mm Body Size

Humidity
35-95% RH, non-condensing

Storage Temperature
-30C to +80C

Control Output
DC 3-wire, NPN Open Collector Output

Electrical Protection
Reverse polarity, Surge, and Overcurrent protection

About AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-8DN, E-X10B1TL18 2M

Experience fresh innovation and instant savings with the AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-8DN E-X10B1TL18-2M. Grab this astonishing device featuring a sterling 17mm resplendent nickel-plated body, offering precise sensing up to 8mm for ferrous metals. Its high-frequency 800Hz response and LED indication provide reliable feedback, while robust electrical protections deliver consistent operation. Ideal for industrial automation, this flush-mountable sensor delivers premium accuracy, detecting metallic objects efficiently without contact. Suitable for conveyors, robotics, and packaging machines, maximize your process control with premium features and effortless integration.

Plant Application & Competitive Edge

Empower your industrial automation plant with the AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-8DN, E-X10B1TL18 2M. Leverage its adjustable sensitivity and robust IP67 rating for seamless operation in demanding environments. Premium detection accuracy, resplendent metal housing, and LED operation indicator offer both durability and dependable feedback. The sensor's sterling performance in conveyors and robotics ensures reliable object detection, quick installation, and minimal maintenance for your plant's competitive advantage.

Main Domestic Market & Transaction Terms

Positioned advantageously in the domestic market, the AUTONICS PROXIMITY SENSOR is available at a premium proposal amount optimized for plant expenditures. Fast payment terms support procurement flexibility, while sample units are available for evaluating sensor quality before a full-scale order. This sterling product is poised to elevate your application standards, ensuring cost-efficient upgrades and minimal downtime with resplendent service and premium technical support for every transaction.

FAQ's of AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-8DN, E-X10B1TL18 2M:

Q: How does the AUTONICS PROXIMITY SENSOR enhance industrial automation processes?

A: The sensor detects metallic objects without physical contact, providing rapid and accurate object recognition, which streamlines automation workflows and increases system efficiency.

Q: What types of applications is this sensor suitable for?

A: It excels in robotics, conveyors, packaging machines, and safety interlocks, thanks to its precise sensing capability and robust construction.

Q: When should I consider using the PSN17-8DN E-X10B1TL18-2M model?

A: Opt for this model when your application requires high accuracy, fast response time, and reliable metallic object detection in challenging industrial environments.

Q: Where can I mount this proximity sensor for optimal performance?

A: The sensor is designed for flush mounting (embeddable) onto surfaces, allowing flexible integration into machinery and automated systems.

Q: What is the process for obtaining a sample of this sensor?

A: Contact your supplier or trader to request a sample unit, allowing you to evaluate performance before committing to bulk procurement.

Q: How does the sensor ensure safe and reliable operation?

A: It incorporates reverse polarity, surge, and overcurrent protection, alongside an IP67 rating and LED status indicator to guarantee continuous and safe operation.
