AUTONICS PROXIMITY SENSOR 12-24VDC, PRT18-8DO

AUTONICS PROXIMITY SENSOR 12-24VDC, PRT18-8DO Specification

Wireless
No

Features
Short-circuit Protection, Overload Protection, Reliable Sensing

Interface
3-Wire, DC

Mounting Type
Flush (Shielded)

Sensor Type
Inductive Proximity Sensor

Cable Length
2m Built-in Cable

Measurement Range
8mm Sensing Distance

Application
Position Sensing, Object Detection

Operating Temperature
-25C to +70C

Power Consumption
20mA

Housing Material
Nickel-plated Brass

Mounting Thread
M18

Response Time
2ms

Sensitivity
Adjustable

IP Rating
IP67

Ingress Protection
IP67

Signal Type
Digital

Product Type
Proximity Sensor

Material
Metal Body

Input
12-24VDC

Output
NPN NO/NC

Function
Detection of Metal Objects

Usage
Industrial Automation

Accuracy
High Accuracy

Voltage
12-24VDC

Weight
Approx. 80g

Connection Type
Pre-wired (2m)

Control Output Current
Max. 200mA

Storage Temperature
-30C to +80C

Indicator
Red LED (Operation Indicator)

Body Diameter
18mm

Frequency Response
Max. 500Hz

Ambient Humidity
35% to 95% RH

Detectable Object Material
Ferrous Metals (Iron, Steel, etc.)

AUTONICS PROXIMITY SENSOR 12-24VDC, PRT18-8DO About

The AUTONICS PROXIMITY SENSOR 12-24VDC, PRT18-8DO is a must-have tool for modern industrial automation. Its remarkable detection of ferrous metals, paired with adjustable sensitivity and impeccable accuracy, ensures reliable object identification. The customizable 8mm sensing distance and robust nickel-plated brass housing deliver spectacular durability under harsh conditions. With IP67 protection and a fresh design, this sensor excels in position sensing and object detection. Integrated short-circuit and overload protection underscore its reliability, making it perfect for any demanding automation environment.

Unmatched Versatility for Industrial Applications

The AUTONICS PROXIMITY SENSOR 12-24VDC, PRT18-8DO is remarkably suitable for use in varied industrial environments. It is ideal for detecting metal objects, making it optimal for position sensing and quality checking applications. Crafted from high-grade metal, it can be seamlessly applied in industries such as automotive, packaging, and manufacturing. Its primary competitive advantages include high accuracy, customizable sensitivity, robust protection features, and impeccable weather resistance, ensuring reliable operation even in the most demanding settings.

Effective Supply and Seamless Delivery

We offer the AUTONICS PROXIMITY SENSOR 12-24VDC, PRT18-8DO from leading ports, ensuring smooth goods transport to your facility. Supply ability is reliable at scale, and sample policies are available on request for initial evaluation. We exchange commitments for quality with each delivery, assuring that every transaction meets your timing and volume needs. Our efficient logistics network reinforces uninterrupted supply for ongoing and future industrial projects.

FAQ's of AUTONICS PROXIMITY SENSOR 12-24VDC, PRT18-8DO:

Q: How does the AUTONICS PROXIMITY SENSOR detect metal objects?

A: The sensor uses inductive technology to generate electromagnetic fields, detecting the presence of ferrous metals such as iron and steel within an 8mm sensing range.

Q: What types of environments are suitable for installing this sensor?

A: Its IP67 rating and wide operating temperature range make it suitable for harsh, humid, and industrial settings, including manufacturing plants and automated assembly lines.

Q: When should I adjust the sensitivity of the sensor?

A: Sensitivity can be customized to match specific object sizes or distance requirements, ensuring optimal detection performance for your application.

Q: Where can I use the PRT18-8DO in my automation process?

A: It is ideal for position sensing, object detection, and quality control in industries such as automotive production, logistics, and packaging operations.

Q: What are the primary benefits of using this proximity sensor in my equipment?

A: Key benefits include impeccable sensing accuracy, remarkable reliability, robust protection features, and easy integration due to its pre-wired design and compatibility with standard DC interfaces.
