AUTONICS PROXIMITY SENSOR 12-24VDC, PRFDAWT08-2DO-IV

AUTONICS PROXIMITY SENSOR 12-24VDC, PRFDAWT08-2DO-IV Specification

Mounting Type
Flush Mount (Shielded)

Measurement Range
2mm (sensing distance)

Features
Reverse polarity protection, Short-circuit protection, LED status indicator

Signal Type
Digital (Open Collector Output)

Interface
3-wire DC Connection

Response Time
<2ms

IP Rating
IP67

Cable Length
2 meters

Sensor Type
Inductive Proximity Sensor

Power Consumption
Max. 12mA

Operating Temperature
-25C to +70C

Sensitivity
Adjustable sensitivity

Application
Position sensing, Process automation

Wireless
No

Product Type
Proximity Sensor

Material
Stainless Steel

Input
12-24V DC

Output
2 NO (Normally Open) PNP

Function
Detection of metallic objects without physical contact

Usage
Industrial Automation, Object Detection

Accuracy
High accuracy detection

Resolution
Precise switching resolution

Voltage
12-24V DC

Weight
Lightweight (Approx. 50g)

Protection Circuits
Surge protection, Overload protection

Switching Frequency
2 kHz

Body Size
M8 (8mm diameter)

Shock Resistance
500m/s2 (approx. 50G)

Max Load Current
200 mA

EMC
IEC61000-4-2, IEC61000-4-3, IEC61000-4-4

Cable Type
PVC insulated, oil resistant

Control Output
PNP, Normally Open (NO), Dual Output

LED Indicator
Red LED for output status

Applicable Standards
CE, RoHS compliant

Housing Material
Nickel-plated brass

Vibration Resistance
10 to 55Hz, 1.5mm double amplitude

AUTONICS PROXIMITY SENSOR 12-24VDC, PRFDAWT08-2DO-IV About

Discover the ultimate value with the AUTONICS PROXIMITY SENSOR 12-24VDC, PRFDAWT08-2DO-IV-currently at a reduced price and ending soon. This rarefied marvel offers high accuracy detection in a compact M8 (8mm) nickel-plated brass housing. Ideal for precise, non-contact object detection in industrial automation, it delivers dual PNP outputs, robust protection circuits, adjustable sensitivity, and a red LED for clear output indication. Engineered to CE and RoHS standards with marvelous reliability, it offers up to 2kHz switching, IP67 protection, and seamless integration. Don't miss this exceptional opportunity!

AUTONICS PROXIMITY SENSOR - Competitive Advantages & Application

The AUTONICS PRFDAWT08-2DO-IV proximity sensor stands out for its lightweight build, high switching frequency, and excellent resistance to vibration and shock. Designed for flush-mount installation in process automation, it supports demanding industrial environments with IP67 rating and dual outputs. Its non-contact, high-precision detection makes it an indispensable tool for object and position sensing in factory automation, conveyor systems, and metal processing applications.

Delivery, Packaging and Payment for AUTONICS Proximity Sensor

Every AUTONICS PRFDAWT08-2DO-IV sensor is securely packaged for safe handling and transport services. Orders are typically handed over within a prompt timeframe, ensuring quick delivery to your site. Payment terms are flexible, designed to suit suppliers, traders, and wholesalers in China and beyond. Trust our reliable logistics and careful packaging to deliver this advanced sensor swiftly and safely to your location.

FAQ's of AUTONICS PROXIMITY SENSOR 12-24VDC, PRFDAWT08-2DO-IV:

Q: How does the AUTONICS PRFDAWT08-2DO-IV proximity sensor improve industrial automation processes?

A: By enabling precise, contactless detection of metallic objects with its high switching frequency and dual PNP outputs, the sensor streamlines position and process automation, reducing errors and increasing operational efficiency.

Q: What protection features does this proximity sensor provide?

A: It offers comprehensive protection including surge and overload protection, reverse polarity, and short-circuit safeguards, ensuring reliability and longevity even in harsh environments.

Q: Where is the optimal place to install the AUTONICS PRFDAWT08-2DO-IV sensor?

A: This sensor is best suited for use in industrial automation, metal processing, conveyor systems, and machinery requiring accurate object or position detection, especially where flush mounting and IP67 protection are essential.

Q: When can I expect delivery after placing an order?

A: Orders are typically processed and handed over to transport services without delay, ensuring prompt delivery. Timelines may vary based on order volume and delivery location, but swift dispatch is prioritized.

Q: What is the process for wiring and integrating the sensor into an automation system?

A: The sensor features a 3-wire DC connection for straightforward installation. Simply follow the wiring diagram, ensure the correct voltage supply (12-24V DC), and connect the output terminals to your system.

Q: What is the benefit of adjustable sensitivity in this sensor?

A: Adjustable sensitivity allows you to fine-tune the detection range according to specific application needs, ensuring maximum accuracy and minimizing false triggers.
