AUTONICS PROXIMITY SENSOR 12-24VDC, PRD08-2DN

AUTONICS PROXIMITY SENSOR 12-24VDC, PRD08-2DN Specification

Signal Type
Digital (ON/OFF)

Operating Temperature
-25C to +70C

Response Time
Max. 2ms

Mounting Type
Flush (Shielded)

Sensitivity
Factory Set

Features
LED Indicator, Short-circuit Protection

Sensor Type
Inductive Proximity Sensor

Measurement Range
Detection Distance: 2mm 10%

Cable Length
2m

Interface
3-wire DC

IP Rating
IP67

Power Consumption
Max. 10mA (No Load)

Application
Automation Equipment, Conveyor Systems

Wireless
No

Product Type
Proximity Sensor

Material
Nickel-Plated Brass

Input
12-24VDC

Output
NPN Normally Open (NO)

Function
Detection of metal objects

Usage
Industrial Automation, Position Sensing

Accuracy
High

Resolution
Standard

Voltage
12-24VDC

Weight
Approx. 30g

Protection Circuit
Surge Protection, Overload Protection

Connection Type
Pre-wired Cable

Reverse Polarity Protection
Yes

Voltage Drop
Max. 1.5V at 200mA load current

Insulation Resistance
Min. 50M (500VDC megger)

Vibration Resistance
10 to 55 Hz, 1.5mm double amplitude

Sensing Face Material
PBT (Polybutylene Terephthalate)

Shock Resistance
500 m/s2 (approx. 50G) 3 times in each direction X, Y, Z

Diameter
M8

Supply Voltage Tolerance
10%

Max. Switching Frequency
1kHz

Housing Length
35mm

About AUTONICS PROXIMITY SENSOR 12-24VDC, PRD08-2DN

Experience the excitement of a Hot-selling, fresh arrival-the AUTONICS PROXIMITY SENSOR 12-24VDC, PRD08-2DN. Engineered for industrial triumph, this breathtaking sensor offers a pristine solution for precise metal detection. Its robust nickel-plated brass housing, reverse polarity protection, and advanced overload safeguards ensure seamless, reliable performance even under extreme vibration or shock. Take advantage of our current discount and secure a top-performing sensor perfect for automation equipment and conveyor systems. Count on rugged durability, high accuracy, and a triumphant performance, every cycle-only from a leading supplier, trader, and wholesaler in China.

Outstanding Features and Versatile Applications

The AUTONICS PROXIMITY SENSOR PRD08-2DN boasts a compact M8 diameter, flush mounting type, and an LED indicator for easy status checks. Its pristine PBT sensing face and strong nickel-plated brass body are built for harsh industrial environments. Factory-set sensitivity ensures precise 2mm detection for metal objects, making it ideal for automation, conveyor systems, and position sensing tasks. Benefit from high vibration and shock resistance, IP67 protection, and reliable operation in ambient temperatures between -25C and +70C.

Export Markets, Terms, and Swift Dispatch

We proudly serve a triumphant network of international clients, ensuring secure shipping and prompt dispatch from leading FOB ports in China. Payment terms are flexible, supporting quick and straightforward exchanges. Whether you need a single unit or bulk supply, our processes guarantee protected packaging and timely delivery to diverse global destinations, minimizing downtime and ensuring customer satisfaction. Trust our expertise as your reliable sourcing partner for automation solutions worldwide.

FAQ's of AUTONICS PROXIMITY SENSOR 12-24VDC, PRD08-2DN:

Q: How does the AUTONICS PROXIMITY SENSOR PRD08-2DN benefit industrial automation?

A: With its high accuracy, fast response time, and robust build, the PRD08-2DN enhances position sensing, metal detection, and error reduction in conveyor and automation systems.

Q: What is the process for installing this proximity sensor?

A: Installation is streamlined with its flush mounting design and pre-wired cable. Simply follow standard wiring procedures, connect to a 12-24VDC source, and use the built-in LED for operational status checks.

Q: When is this sensor most commonly used in industrial settings?

A: The PRD08-2DN is commonly used during metal object detection, position sensing, and automated control in conveyor systems, robotic arms, or any system demanding reliable, contactless switching.

Q: Where can the AUTONICS PRD08-2DN be applied for optimal performance?

A: It excels in harsh industrial environments requiring high vibration and shock resistance, such as automated assembly lines, packaging equipment, and material handling systems.

Q: What makes this proximity sensor hot-selling in export markets?

A: Its pristine build quality, advanced protection circuits, and compatibility with a wide range of automation setups make it a sought-after choice among global customers seeking reliability and precision.
