AUTONICS PROXIITY SESNSOR 12-24VDC, PRL30-15DN

AUTONICS PROXIITY SESNSOR 12-24VDC, PRL30-15DN Specification

Cable Length
2 meters

Mounting Type
Threaded/cylindrical

Application
Position detection, Counting, Automation machinery

Features
Non-contact detection, Long life, Oil and dust resistant

Power Consumption
Max. 1.5W

Mounting Thread
M30

Housing Material
Nickel-plated brass

Signal Type
Discrete (On/Off)

Sensitivity
Adjustable depending on target

Wireless
No

IP Rating
IP67

Sensor Type
Inductive Proximity Sensor

Ingress Protection
IP67

Operating Temperature
-25C to +70C

Measurement Range
15 mm (sensing distance)

Interface
3-wire DC

Response Time
<2ms

Product Type
Proximity Sensor

Material
Metal

Input
12-24VDC

Output
NPN Normally Open (NO)

Function
Sensing detection of objects

Usage
Automation, Industrial

Accuracy
High

Resolution
Standard

Voltage
12-24VDC

Weight
Approx. 210g (with cable)

Part Number
PRL30-15DN

Standard/Approval
CE, UKCA, EAC, RoHS compliant

Housing Size
M30 x 15mm detection face

Connection Type
Pre-wired

LED Indicator
Operation indicator (LED)

Detection Object
Ferrous metals (best), reduced for non-ferrous

Protection Circuit
Reverse polarity, Surge protection

Max Switching Current
200mA

Operating Frequency
400Hz

AUTONICS PROXIITY SESNSOR 12-24VDC, PRL30-15DN Trade Information

Minimum Order Quantity
2 Pieces

Delivery Time
5-7 Days

AUTONICS PROXIITY SESNSOR 12-24VDC, PRL30-15DN About

Access superior automation solutions with the AUTONICS PROXIMITY SENSOR 12-24VDC, PRL30-15DN, now available at a compelling price cut. Highly recommended for industries seeking enlightened technology, this invincible sensor boasts sublime accuracy, robust nickel-plated brass housing, and an IP67 rating for durability. Its pre-wired configuration ensures seamless integration, while advanced protection circuits guard against power surges. Suited for ferrous metal detection with a swift response time, the PRL30-15DN elevates efficiency and reliability in position detection, counting, and automated machinery applications. CE, UKCA, EAC, and RoHS compliant.

Versatile Application Across Surfaces and Plants

The AUTONICS PROXIMITY SENSOR 12-24VDC, PRL30-15DN excels in diverse application surfaces, from industrial conveyor systems to precise plant automation processes. Its durable metal housing and non-contact detection adapt well to various surface materials-especially ferrous metals-making it ideal for assembly lines, packaging machinery, and equipment positioning tasks. The sensor's rugged design withstands rigorous plant environments, ensuring reliable performance wherever position detection or automated counting is needed across your facility.

Flexible Payment, Sample Policy, and Quick Access

Experience streamlined procurement with flexible payment terms tailored to your operation's needs. Samples are available, allowing you to assess product performance before any major outlay. With stock ready at our FOB port, you can swiftly exchange orders for immediate dispatch. Our smooth transaction process ensures you can rapidly integrate this high-performance proximity sensor into your automation or industrial systems with minimal delay, enhancing your production efficiency.

FAQ's of AUTONICS PROXIITY SESNSOR 12-24VDC, PRL30-15DN:

Q: How does the AUTONICS PRL30-15DN proximity sensor benefit industrial automation?

A: The PRL30-15DN provides highly accurate, non-contact detection of ferrous objects, ensuring reliable position feedback and object counting in automation and industrial machinery, helping to improve efficiency and reduce maintenance downtime.

Q: What surfaces and environments is this proximity sensor suitable for?

A: This sensor is optimized for ferrous metal detection on conveyor belts, packaging lines, and factory automation equipment. Its IP67 rating and robust construction make it suitable for harsh, oil- and dust-prone environments.

Q: When is the product available for dispatch?

A: The AUTONICS PRL30-15DN is stock ready for immediate dispatch from our FOB port. Orders can be processed and shipped promptly to match your project's turnaround requirements.

Q: Where can I use the AUTONICS PROXIMITY SENSOR in my facility?

A: You can implement it at various automation points-such as assembly lines, position detection modules, or machinery requiring object or part verification-across your factory or industrial plant.

Q: What is the process to request a product sample?

A: To request a sample, contact our sales team with your requirements. We'll coordinate the sample policy details with you to facilitate evaluation prior to making a larger purchase.

Q: How does the sensor's protection circuit enhance longevity?

A: Built-in reverse polarity and surge protection circuits shield the sensor from electrical faults, ensuring a longer service life and greater reliability in continuous industrial operations.
