AUTONICS PHOTOELECTRIC SENSOR,BRQM3M-PDTA-P

AUTONICS PHOTOELECTRIC SENSOR,BRQM3M-PDTA-P Specification

Operating Temperature
-25C to +55C

Features
Reverse Polarity Protection, Short-circuit Protection

IP Rating
IP67

Interface
3-Wire DC

Sensor Type
Diffuse Reflective

Wireless
No

Cable Length
2 meters

Sensitivity
Adjustable

Signal Type
Digital

Mounting Type
Panel/Bracket Mount

Response Time
Max. 1ms

Measurement Range
0-300mm (Adjustable)

Application
Industrial Automation, Conveyor Systems, Presence Sensing

Power Consumption
Max 25mA

Product Type
Photoelectric Sensor

Material
Plastic Housing

Input
12-24V DC

Output
PNP/NPN Open Collector

Function
Detection / Sensing

Usage
Object Detection, Automation Systems

Accuracy
High Precision Sensing

Resolution
Standard

Voltage
12-24V DC

Weight
Approx. 40g

Storage Temperature
-30C to +70C

Dielectric Strength
1000V AC, 50/60Hz for 1 min

Model Number
BRQM3M-PDTA-P

Status Indication
LED Indicator for Output

Hysteresis
Less than 15% of sensing distance

Shock Resistance
500m/s (approx. 50G)

Light Source
Red LED (660nm)

Control Output
PNP Type

Connection Type
Pre-wired

Insulation Resistance
20M min. (at 500V DC)

Detection Method
Diffuse Reflective Type

Maximum Load Current
100mA Max.

Vibration Resistance
10-55Hz, 1.5mm amplitude

Enclosure Material
Polycarbonate

AUTONICS PHOTOELECTRIC SENSOR,BRQM3M-PDTA-P About

Experience distinguished sensing accuracy with the AUTONICS PHOTOELECTRIC SENSOR, BRQM3M-PDTA-P. Crafted with a lustrous polycarbonate enclosure and equipped with a gorgeous Red LED (660nm) light source, this in-demand sensor offers high precision object detection in industrial automation environments. Featuring a diffuse reflective detection method, adjustable sensitivity, and robust PNP control output, it ensures reliable performance and is easy to integrate with a pre-wired 3-wire DC interface. With versatile mounting options, a Markdown on bulk offers, and IP67 protection, this sensor is ideal for conveyor systems and presence sensing, making it a sought-after choice among suppliers, traders, and wholesalers across China.

Versatile Applications & Use Cases

The AUTONICS BRQM3M-PDTA-P Photoelectric Sensor is widely utilized for object detection and presence sensing in industrial automation. Its use type is suited for panel or bracket mounting, making it highly adaptable for conveyor systems and automated machinery. Designed for high precision detection, it's essential in manufacturing facilities, packaging lines, and logistics sorting, where accurate measurement and durability are paramount, supporting advanced automation solutions efficiently.

Payment, Policies & Certifications

Handover of the AUTONICS PHOTOELECTRIC SENSOR, BRQM3M-PDTA-P is ensured with secure payment terms, including options for bank transfer and letter of credit. Packing & dispatch procedures follow international standards to guarantee product safety during shipment. Samples can be provided as per the supplier's policy for evaluation before full order placement. Each sensor is shipped with relevant certifications, confirming compliance with safety and quality standards for industrial use.

FAQ's of AUTONICS PHOTOELECTRIC SENSOR,BRQM3M-PDTA-P:

Q: How does the AUTONICS BRQM3M-PDTA-P Photoelectric Sensor contribute to automation systems?

A: The sensor supports reliable object detection and presence sensing, ensuring seamless automation on conveyor lines and industrial machinery with its high precision and quick response time.

Q: What are the main benefits of using a diffuse reflective sensor type in applications?

A: Diffuse reflective sensors allow easy installation, do not require a separate reflector, and offer flexible detection for objects of varying materials and colors, enhancing convenience in automation environments.

Q: Where can the BRQM3M-PDTA-P sensor be utilized most effectively?

A: It performs exceptionally in industrial automation, conveyor systems, packaging lines, and logistics centers, wherever accurate object presence detection is required in demanding environments.

Q: What process is followed for packing, dispatch, and shipment of the sensor?

A: Packing and dispatch adhere to international safety standards, ensuring the sensor is securely packaged and shipped to prevent damage during transit, guaranteeing customer satisfaction upon handover.

Q: How is the sensitivity and measurement range of the sensor adjusted?

A: Sensitivity is adjustable via the onboard controls, allowing users to optimize the detection range between 0 to 300mm according to application requirements for improved accuracy.

Q: What certifications accompany the AUTONICS BRQM3M-PDTA-P upon delivery?

A: The sensor is delivered with certifications affirming compliance with industrial safety, quality, and electrical standards, ensuring suitability for professional automation and object detection use.
