AUTONICS FIBER OPTIC SENSOR, BF5R-D1-P

AUTONICS FIBER OPTIC SENSOR, BF5R-D1-P Specification

Sensitivity
Adjustable

Cable Length
2 meters

Operating Temperature
-10C to +55C

Wireless
No

Power Consumption
Max. 960mW

Features
Bright dual-indicator, stable sensing, compact design, easy installation

Mounting Type
DIN Rail or Screw Mounting

Application
Object detection, counting, positioning, and presence detection

Response Time
500s or less

Signal Type
Digital

IP Rating
IP40

Sensor Type
Photoelectric Fiber Optic Sensor

Interface
Connector terminal or cable

Measurement Range
Depends on fiber optic cable (up to several meters)

Product Type
Fiber Optic Sensor

Material
Plastic

Input
12-24V DC

Output
PNP open collector

Function
Detection of objects using fiber optics

Usage
Industrial automation and sensing applications

Accuracy
High

Resolution
Fine adjustment available

Voltage
12-24V DC 10%

Weight
Approximately 90g

Life Expectancy
Over 100,000 hours (LED life)

Short Circuit Protection
Yes

Display
Operation indicator (red LED) and stability indicator (green LED)

Control Output
PNP NO/NC (Selectable)

Housing Material
Polycarbonate

Reverse Polarity Protection
Yes

Shock Resistance
500m/s2 (approx. 50G) in X, Y, Z directions, 3 times each

Light Source
Red LED

Ambient Humidity
35 to 85% RH

Vibration Resistance
10 to 55 Hz, amplitude 1.5mm, in each of X, Y, Z directions for 2 hours

About AUTONICS FIBER OPTIC SENSOR, BF5R-D1-P

Experience formidable precision in industrial automation with the latest AUTONICS FIBER OPTIC SENSOR, BF5R-D1-P. Designed as a must-have for demanding applications, this sensor features a high-resolution, stable sensing solution empowered by a grand Red LED light source. With triumphant reliability, it offers reduced errors and enhanced safety through reverse polarity and short circuit protection. Rugged construction ensures it withstands intensive shocks and vibrations, while adjustable sensitivity and dual indicators provide intuitive, accurate object detection. Ideal for counting, positioning, and presence detection, this compact sensor is engineered for lasting performance and easy installation.

Versatile Application Areas and Users

The AUTONICS FIBER OPTIC SENSOR, BF5R-D1-P is widely trusted by quality control engineers, machine designers, and automation specialists. Utilized in assembly lines, packaging systems, robotics, and inspection stations, it ensures precise object detection for counting, positioning, and presence verification. Its reliability extends to electronics manufacturing, pharmaceuticals, and logistics, making it suitable for diverse industrial sectors demanding impeccable performance and accuracy.

Global Market Access and Sample Dispatch

AUTONICS BF5R-D1-P commands a strong presence in grand export markets across Asia, Europe, and the Americas. Sale price estimates and flexible payment terms are available upon inquiry, ensuring smooth global transactions. Prompt sample dispatching is offered to facilitate customer evaluation and satisfaction. This commitment to efficient service ensures traders and wholesalers can confidently distribute the sensor while meeting urgent industrial automation demands.

FAQ's of AUTONICS FIBER OPTIC SENSOR, BF5R-D1-P:

Q: How does the AUTONICS BF5R-D1-P sensor ensure reliable detection in harsh environments?

A: The sensor is crafted with robust polycarbonate housing and features high resistance to vibrations and shocks, making it ideal for harsh industrial settings. Its IP40 rating offers reliable operation in typical factory environments.

Q: What are the main applications for the AUTONICS BF5R-D1-P fiber optic sensor?

A: It excels in object detection, counting, positioning, and presence verification in automation systems, assembly lines, robotics, and packaging solutions, catering to varied industrial automation needs.

Q: When should users consider selecting the BF5R-D1-P model for their projects?

A: Users should opt for the BF5R-D1-P when applications require high accuracy, fine resolution, adjustable sensitivity, and stable performance amidst demanding industrial conditions.

Q: Where can the AUTONICS BF5R-D1-P sensor be mounted?

A: The sensor supports both DIN rail and screw mounting, offering flexibility for seamless integration into diverse equipment layouts.

Q: What benefits do the dual indicator lights provide to operators?

A: The operation (red LED) and stability (green LED) indicators offer real-time feedback, allowing operators to monitor sensor status and quickly calibrate or troubleshoot as needed.
