AUTONICS FIBER OPTIC SENSOR, BF5R-D1-N

AUTONICS FIBER OPTIC SENSOR, BF5R-D1-N Specification

Mounting Type
DIN Rail Mountable

Interface
Cable connection

Features
Red LED for output indication, Stable operation, Compact size

Sensitivity
Adjustable (8-turn potentiometer)

Signal Type
Digital (NPN)

Operating Temperature
-10C to +50C

Cable Length
2m attached cable

Wireless
No

Sensor Type
Digital Fiber Optic Amplifier

IP Rating
IP40

Power Consumption
Max. 40mA

Response Time
Max. 0.5ms

Application
Industrial Machine Sensing, Conveyor Systems, Robotics

Measurement Range
Depends on fiber unit (generally up to several meters)

Product Type
Fiber Optic Sensor

Material
Plastic Housing, Polycarbonate Cover

Input
12-24V DC

Output
NPN Open Collector

Function
Object Detection, Sensing

Usage
Industrial Automation, Position Sensing

Accuracy
High accuracy (typ. <1mm, depending on fiber head)

Resolution
Adjustable sensitivity setting for fine detection

Voltage
12-24V DC (Operating voltage range: 10-30V DC)

Weight
Approx. 85g

Response Frequency
Up to 2kHz

Shock Resistance
500m/s² (approx. 50G) (X,Y,Z each 3 times)

Model Number
BF5R-D1-N

Dimensions
31mm(H) x 19mm(W) x 75mm(L)

Ambient Humidity
35 to 85% RH

Enclosure Protection
IP40 (IEC standards)

Indicator
Red LED (Output), Green LED (Stability)

Control Method
Light ON/Dark ON switch selectable

Light Source
Red LED (660nm)

Vibration Resistance
10-55Hz, amplitude 1.5mm (X,Y,Z each 2h)

About AUTONICS FIBER OPTIC SENSOR, BF5R-D1-N

Jump on this exceptional opportunity to secure the AUTONICS FIBER OPTIC SENSOR, BF5R-D1-N for your advanced automation needs. With a sterling Red LED (660nm) light source and adjustable high accuracy (typ. <1mm) sensitivity, this digital amplifier is ideal for precision industrial sensing. Get valuable object detection and stable position monitoring across conveyor systems or robotics applications. Robust IP40 protection, vibration and shock resistance, DIN rail mountability, and efficient NPN open collector output make this a limited-time essential for modern industries. Don't miss out!

Application and Usage Highlights

The AUTONICS FIBER OPTIC SENSOR, BF5R-D1-N is perfectly suited for industrial sites, particularly within conveyor systems, robotics, and machinery requiring high-precision position sensing. Application is seamless-DIN rail mounting and a 2-meter attached cable facilitate quick integration. Its usage type encompasses both object detection and fine sensing tasks in automation setups. With adjustable sensitivity and high response rates, it's tailored for reliable operation in demanding industrial environments.

Certifications, Packaging & Sample Policy

Each AUTONICS BF5R-D1-N fiber optic sensor is delivered with a valuation that reflects its industry-standard credentials. Packaging is secure to ensure pristine arrival, with each unit compactly boxed for efficient shipping. List price options, sample availability, and flexible sample policy are available-ideal for traders or wholesalers evaluating bulk acquisition. With quality certifications inline with IEC standards, the sensor meets performance and safety requirements indispensable for modern automation projects.

FAQ's of AUTONICS FIBER OPTIC SENSOR, BF5R-D1-N:

Q: How is the AUTONICS BF5R-D1-N fiber optic sensor installed in industrial setups?

A: Installation is straightforward using DIN rail mounting and the attached 2m cable. Simply secure the sensor onto the DIN rail, connect the cable, and it's ready for integration into automation systems.

Q: What is the main benefit of using the BF5R-D1-N in conveyor systems?

A: The main benefit is its exceptional precision in detecting objects and positions, ensuring reliable control processes and minimizing system errors in conveyor or robotic automation.

Q: Where can this fiber optic sensor be applied most effectively?

A: This sensor excels in industrial applications like machine sensing, conveyor automation, robotics, and any scenario requiring high-accuracy detection and position monitoring.

Q: What method is used to adjust the sensitivity of the BF5R-D1-N sensor?

A: Sensitivity can be finely tuned using the built-in 8-turn potentiometer, allowing you to adapt the sensor's response to varying environmental and system requirements.

Q: When should traders or wholesalers consider requesting a sample of the BF5R-D1-N?

A: Request samples when evaluating new industrial sensors for bulk purchase, or when you need to conduct valuation checks for compatibility and performance within your systems.
