AUTONICS AREA SENSOR 12-24VDC, BWP20-12

AUTONICS AREA SENSOR 12-24VDC, BWP20-12 Specification

Application
Detection of objects and parts on assembly/packaging lines

Cable Length
Standard 2m

Response Time
Max. 10ms

Signal Type
Digital (ON/OFF optical output)

Operating Temperature
-10°C to +50°C (No freezing or condensation)

Features
Slim body, multiple beam channels, built-in operation indicator

Sensor Type
Transmissive, Opposed type

Sensitivity
Fixed (not adjustable)

IP Rating
IP40

Wireless
No

Interface
3-wire DC

Power Consumption
Max. 120mA per unit

Measurement Range
0.1m to 3m

Mounting Type
Side bracket mounting

Product Type
Area Sensor

Material
Polycarbonate (housing), PMMA (lens)

Input
12-24V DC ±10% (ripple P-P: max. 10%)

Output
NPN Open Collector

Function
Object detection and presence sensing across area

Usage
General industrial automation, conveyor and packaging lines

Accuracy
±1mm (within sensing area)

Resolution
20mm (beam pitch)

Voltage
12-24V DC

Weight
Approx. 380g (per unit)

Connection Method
Pre-wired cable

Maximum Load Current
100mA (at 30V DC)

Special Function
Buzzer function for operation status

Ambient Humidity
35% to 85% RH (non-condensing)

Number of Optical Axes
12 channels

Light Source
Infrared LED (wavelength: 870nm)

Beam Pitch
20mm (between centers of adjacent lenses)

Protection Circuit
Reverse polarity, output short-circuit, surge protection

Residual Voltage
1V max. (at load current: 100mA)

AUTONICS AREA SENSOR 12-24VDC, BWP20-12 About

Unlock the potential of your automation setup with the AUTONICS AREA SENSOR 12-24VDC, BWP20-12. This sought-after, top-tier area sensor features 12 optical axes and world-class infrared LED technology (870nm), ensuring high accuracy (1mm) with a 20mm resolution. Its built-in protection circuit minimizes downtimes, while the reduced power consumption (max. 120mA) helps cut overall costs. Enjoy the benefit of exclusive discounts from a trusted supplier, trader, and wholesaler in China. Ideal for demanding conveyor and packaging lines, it delivers sharp operational feedback via a buzzer and indicator.

High-Performance Features and Versatile Applications

The AUTONICS AREA SENSOR 12-24VDC, BWP20-12 boasts a slim design, 12 precise optical channels, and a robust buzzer function for real-time status. Crafted with durable polycarbonate and PMMA materials, it's engineered for world-class object detection in challenging industrial environments. Perfect for general automation, assembly, and packaging lines, it offers reliable presence sensing and quick reactions, granting operators a significant advantage in maximizing production efficiency and reducing downtime.

Consistent Supply, Secure Packaging, and Efficient Export

Experience peace of mind with our dependable supply ability for the AUTONICS AREA SENSOR BWP20-12. Each sensor is carefully packaged for safe transportation, guaranteeing intact delivery worldwide. We offer the lowest price to wholesalers, traders, and industrial buyers, making it an economical choice for volume purchasing. Our main export markets include Europe, Asia, and North America, ensuring prompt delivery no matter where your operations are located.

FAQ's of AUTONICS AREA SENSOR 12-24VDC, BWP20-12:

Q: How does the AUTONICS AREA SENSOR BWP20-12 enhance efficiency on assembly and packaging lines?

A: The AUTONICS AREA SENSOR BWP20-12 provides precise object and presence detection using 12 optical axes and a fast response time (max. 10ms), enabling quick and reliable automation for conveyor and packaging lines.

Q: What are the main features that set this area sensor apart from competitors?

A: Key features include a slim body, built-in buzzer for operation status, multiple beam channels, robust protection circuits, and durable construction from polycarbonate and PMMA.

Q: Where can the AUTONICS AREA SENSOR BWP20-12 be best utilized?

A: This sensor is ideal for use in general industrial automation, particularly conveyor and packaging lines where accurate and rapid object detection is essential.

Q: What packaging and transportation measures are in place for safe delivery?

A: Each sensor is securely packaged to prevent damage during transportation, ensuring it arrives safely whether shipped locally or exported overseas.

Q: How can buyers benefit from purchasing this sensor through your trading channel?

A: Buyers enjoy reduced prices, prompt delivery, and full support from a reliable supplier, making it a smart investment for large-scale procurement.

Q: What is the process for installing the AUTONICS AREA SENSOR BWP20-12?

A: Mounting is straightforward using side bracket mounting and the pre-wired 2m cable, with clear operation indicators and a fixed sensitivity feature for simple setup.
