OMRON RELAY 220-240VAC, MY4N-GS-R, E3JK-DP14, D4SL-N2DFA,D4SL-NSK10-LKH

OMRON RELAY 220-240VAC, MY4N-GS-R, E3JK-DP14, D4SL-N2DFA,D4SL-NSK10-LKH Specification

Ambient Temperature
-25C to +60C

Coil Power
1.2 VA (Relay)

Mechanical Life
10,000,000 operations min.

Protect Feature
Dust Cover, IP65 (Sensor/Switch)

Contact Resistance
100 m max. (at 1A 6VDC)

Contact Form
4PDT/DPST

Working Temperature
-25C to +60C

Coil Voltage
220-240VAC

Contact Material
Ag Alloy

Power Consumption
Approx. 1.2VA (Relay), <50mA (Sensor/Switch)

Dielectiric Strength
2000VAC, 50/60Hz for 1 min between coil & contacts

Product Type
Electromechanical Relay, Photoelectric Sensor, Safety Door Switch

Insulation Resistance
1000 M min. (at 500VDC)

Theory
Electromagnetic, Optical, Mechanical Interlock

Usage
General Purpose, Automation, Safety interlocking, Photoelectric Detection

Contact Load
5A 250VAC / 30VDC (resistive load)

Operate Time
20 ms max.

Terminal Type
Plug-in/Screw Terminal

Rated Voltage
220-240VAC

Supply Terminal
Screw/Plug-up

Size
Compact (Standard 35mm width for relay, sensor 50mm x 18mm x 50mm)

Color
Black, Transparent, Grey

Dimension (L*W*H)
Relay: 28 x 21.5 x 36mm, Sensor: 50 x 18 x 50mm, Switch: 120 x 40 x 40mm

Weight
Approx. 63g (Relay), 110g (Sensor/Switch)

Switch Lock Type
Solenoid Locking (D4SL-N2DFA)

Detection Distance
300 to 700mm (adjustable, E3JK-DP14)

EN/IEC Standards
EN60947-5-1, IEC60947-5-1 (For D4SL, E3JK series)

Release Time
20 ms max. (Relay)

Mounting Method
Panel, DIN Rail, Surface mount (depending on model)

Activation Method
Electromagnetic Relay, Photoelectric Detection, Mechanical Key Insert

Control Output
Relay or PNP/NPN open collector (sensor)

Sensor Type
Photoelectric, Diffuse Reflective (E3JK-DP14)

Cable Entry
M20 or prewired

Safety Switch Type
Locking Type, Key Operated (D4SL-N2DFA, D4SL-NSK10-LKH)

Response Time
1 ms (E3JK-DP14)

Shock Resistance
1000 m/s2 (relay), 300 m/s2 (sensor/switch)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Contact Configuration
4NO+4NC (MY4N-GS-R), DPST (Switch)

Enclosure Material
Flame-retardant plastic, Polycarbonate (sensor)

Operation Voltage Range
80% to 110% of rated coil voltage

LED Indicator
Yes (on relay and sensor for operation status)

About OMRON RELAY 220-240VAC, MY4N-GS-R, E3JK-DP14, D4SL-N2DFA,D4SL-NSK10-LKH

Take advantage of this formidable clearance offering, featuring the OMRON RELAY 220-240VAC, MY4N-GS-R, E3JK-DP14, D4SL-N2DFA, and D4SL-NSK10-LKH. This lineup is an astounding integration of masterful engineering for general automation, safety interlocking, and photoelectric detection. With photoelectric sensing up to 700mm, robust relay designs, and mechanical key-operated safety switches, these components deliver unwavering reliability. Each unit boasts LED indicators, advanced protection, and compliance with stringent EN/IEC standards. Add to Cart now and elevate your automation with this masterpiece for unprecedented performance and durability.

Versatile Application and Usage

OMRONs RELAY MY4N-GS-R, E3JK-DP14, D4SL-N2DFA, and D4SL-NSK10-LKH are crafted for general purpose automation, safety interlocking, and photoelectric object detection applications. Their configurable mounting optionspanel, DIN rail, or surfacemake them ideal for production lines, machinery control, and access safety systems in manufacturing, logistics, and warehouses. With solenoid locking and advanced optical sensors, these units serve as critical solutions in modern industrial environments.

Sample Policy and Shipping Details

We offer sample policies for evaluating the OMRON relay and sensor series. Our FOB Port serves as the primary dispatching hub to ensure rapid and reliable delivery. With robust supply ability, we accommodate both small and bulk orders. Freight is arranged according to customer requirements, and our secure shipping methods safeguard products against transit damage. Enjoy streamlined order processing for fast, worry-free shipment directly to your facility.

FAQs of OMRON RELAY 220-240VAC, MY4N-GS-R, E3JK-DP14, D4SL-N2DFA,D4SL-NSK10-LKH:

Q: How can the OMRON MY4N-GS-R relay benefit my automation processes?

A: The MY4N-GS-R relay offers fast response time, high mechanical endurance, and versatile control outputs, making it ideal for reliable automation, ensuring safe and efficient control over machinery.

Q: What detection range does the E3JK-DP14 photoelectric sensor provide?

A: The E3JK-DP14 features a diffuse reflective sensor with an adjustable detection range of 300 to 700mm, catering to various application needs for object recognition and sorting.

Q: Where can these OMRON components be installed in an industrial setting?

A: These components can be mounted on panels, DIN rails, or surfaces, suitable for integration into manufacturing lines, machinery panels, logistics conveyors, and safety interlocking systems.

Q: When is it necessary to use a solenoid locking safety switch like the D4SL-N2DFA?

A: A solenoid locking safety switch is crucial when access to hazardous areas must be strictly controlled, ensuring machines remain inoperative until safe conditions are confirmed.

Q: What is the process for ordering samples and receiving products?

A: You may request samples as per our policy. Orders are processed promptly, dispatched from the designated FOB Port, and delivered securely via coordinated freight according to your requirements.
